Radar & Video all-in-one Vehicles Detect Machine

n Applicable to signal control systems, traffic information service systems, road traffic monitoring and other application scenarios.

n High precision millimeter wave radar with 4 million low illumination camera.

n Max. 8 lanes of multi-target motor vehicles detection, longitudinal distance of 100m.

n High spatial resolution and strong penetration ability, support working in all-weather environment, not affected by rain, fog, strong wind, dust, light, etc.

n Built-in deep learning algorithm, support intelligent recognition function, support license plate recognition and target fully structured.

n Supports detection of multiple targets’ position, lane, speed, direction and other info.

n It supports lane statistics, traffic flow, speed, status, queue, time distance, spacing, Qty.of parking areas, avg.delay, space occupancy and time occupancy data, and supports statistical upload from 1 to 3600 seconds.

n Supports traffic evaluation data output, including congestion, queue length, etc.

n Each lane supports 2 virtual coils to output vehicle entry and exit signals, the virtual coil positions are configurable.

n Fog penetration, strong light suppression, wide dynamic range, and has multiple white balance modes to suit various scene requirements.

n Support Network & RS-485 data upload.

Parameters

Millimeter Wave Radar

Target Type

People / Motor Vehicles / Non-Motor Vehicles

Max. Qty. of Detection

128

Working Frequency

80 ~ 81GHz

Transmit power

12dBm(RFout)+18dB(ANTgain)

Speed Detect Range

-250 km/h ~ 250 km/h

Detection Mode

Doppler moving target detection, slow moving target detection, fast moving target detection

Sweep bandwidth

136.5 MHz

Modulation Waveform

FMCW

Max. Detection Distance

150m@0° ;    50m@士45°

Horizontal angle measurement range

士45°

Horizontal lobe

90° for MRR, 22° for  LRR

Vertical Lobe

13°(-6dB)

Refresh rate

12.5Hz

Install Height

1~ 6m

Interface

Serial Port

1 of RS-485 Port

Snapshot Function

Image Format

JPEG

Image resolution

2688 × 1520

Smart Functions

Intelligent recognition

Bayonet capture, license plate recognition, vehicle model recognition, vehicle body color recognition, brand, sub-brand.

Exterior Interface

Ethernet

2pcs RJ45 100 M / 1000 M Adaptive Ethernet port

Warning

1 Relay switch

Function Features

Min.illumination

Colorful: 0.01 Lux @ (F1.2，AGC ON)
Black & White: 0.001 Lux @ (F1.2，AGC ON)

shutter

1/25s ~ 1/100,000s

Video compression standards

H.264, H.265, MJPEG

Compression output bit rate

32 Kbps ~ 16 Mbps

Video resolution

2688 × 1520

Frame rate

25 fps (2688 × 1520)

Image Settings

Saturation, brightness, contrast, white balance, gain adjustable through software

Storage function

TF

General functions

Heartbeat, password protection, NTP time synchronization

Video format

PAL

General Specifications

Dimmensions

226 mm (W) x 375.3 mm (H) x 206.4 mm (D)

Working Temperature

-30 °C ~ +70 °C

Working Humidity

5% ~ 95% @ 40 °C，No condensation

Working Voltage

DC 24 V ± 10%

Power Consumption

25 W Max.

N.W.

3 kg

ICR Type

Infrared

IP Rating

IP67

Focal Length

12 mm

Resolution

2688 × 1520

White Balance

Automatic white balance

Wide dynamic range

Support
